| Available in | Reverse Cycle - 5.0kW |
| Refrigerant | R32 |
Key features
.jpg?sfvrsn=2e87593d_1)
Technical Specifications
| Attribute | ABTH18KRTA 5.00kW(C) 5.00kW(H) View model |
|---|---|
|
Operation Type
|
Reverse Cycle |
|
Power Source
V/Ph/Hz
|
230 / 1 / 50 |
|
Capacity Class
kW
|
5 |
|
Running Current
amps (Cooling / Heating)
|
0.21 / 0.21 |
|
Indoor Sound Pressure Cooling
dBA (High / Quiet)
|
38 / 31 |
|
Indoor Sound Pressure Heating
dBA (High / Quiet)
|
38 / 31 |
|
Air Circulation (Indoor - High Fan) Cooling
l/sec
|
233 |
|
Air Circulation (Indoor - High Fan) Heating
l/sec
|
233 |
|
Indoor Unit Dimensions
mm (Height x Width x Depth)
|
235 x 1080 x 705 |
|
Indoor Unit Weight
kg
|
24.00 |
|
Piping Connects
mm Ø (Liquid / Gas)
|
6.35 / 12.7 |
|
Operation Range Cooling
°CDB (Min to Max)
|
18 to 32 |
|
Operation Range Heating
°CDB (Min to Max)
|
16 to 30 |
|
Refrigerant Type
|
R32 |
|
UART Communication
|
Yes |
|
UART Communication Port
|
2 Ports - CN65, CN75 |
Show all specifications
Collapse all specifications
